SJMC-Disc valve

Product Overview

The disc valve is a type of valve widely used in various industrial fields, characterized by its simple structure, convenient operation, good sealing, and long service life. This valve is mainly suitable for industries such as coal, ore, metallurgy, and papermaking, which involve dusty gases. Depending on application requirements, the disc valve can be configured with different driving methods, sealing materials, and corrosion-resistant materials to meet the needs of different working conditions

Performance features

1. Good sealing: The disc valve adopts a composite sealing structure of metal and non-metal materials, which can ensure sealing under harsh working conditions

2. Good wear resistance: The sealing surface of the disc valve adopts high-resistant materials, which can effectively extend the service life

3. corrosion resistance: The metal part of the disc valve has been specially treated and has good corrosion resistance

4. Good anti-scaling: The surface of the disc valve been precisely machined, which can effectively prevent scaling and ensure the smooth opening and closing of the valve

5. Strong flow capacity: The flow channel of the disc is designed reasonably, which can ensure the flow capacity of large flow and high flow rate media

6. Easy maintenance: The components of the disc valve adopt standardized design which is easy to replace and maintain

7. Wide range of applications: The disc valve is suitable for various industrial fields, such as the transportation of coal, ore grain and other materials

Technical parameters

1. Flue cross section: W (width) x H (height) x L (thickness)

2. Flue cross section DN (flue inner diameter) x L (thickness)

3. Installation position: horizontal flue, vertical flue, inclined flue

4. Medium of: cold, hot air or smoke

5. Design pressure bearing capacity: ≤50KPa

6. Design temperature resistance: ≤450°C .

7.troke: 0~90°

8. Leakage rate: ≤0.1%
