Auma-Multi-turn actuator - SVM/SVMR series

The "small" electric globe valve actuator range with integral controls. All parameters are directly set at the actuator. The controls contain switchgear, power supply unit, interface to the DCS. The controls automatically switch the actuator off once the valve end position is reached, motor overheating is detected or a torque overload has occurred.

All housing components are made of bronze, all external screws are made of stainless steel. This ensures complete resistance against seawater even over a longer time period.

The SVM actuators are designed for open-close duty and positioning duty (classes A and B) / (short-time duty S2 - 15 min), the SVMR actuators for modulating duty (class C) S4 - 40%.

Torque range

10 Nm to 100 Nm

Seawater resistant for open-close and modulating duty
